System

System Cable

CAT5 FTP cable 2x4x24 AWG Solid Wire

Maximum Distance

150m/500ft

Keyboard & Mouse support

USB keyboard and mouse

Operating Systems

Win and Linx

Management

Push button or external control unit

Screen resolution

Up to 1600X1200 @ 75Hz

Operating Temperature

0° C to 40° C/32° F to 104° F

Storage Temperature

-40° C to 70° C/-40° F to 158° F

TRANSMITTER

RECEIVER

Cables & Connectors

HDD15F (VGA+USB cable) - for computer or KVM switch
HDD15 - for monitor
USB x 2: Console KB/M
RJ45 - System
RJ11 - External control unit

HDD15F (VGA+USB cable) - for optional local computer
HDD15 - monitor
USB x 2: Console KB/M
RJ45 - System
RJ11 - External control unit

Dimensions

85 x 113 x 25mm / 3.3" x 4.4" x 0.98"

85 x 49 x 25mm / 3.3" x 4.4" x 0.98"

Power supply

From computer or external power adapter 12VDC 1A

External power adapter 12VDC 1A

Shipping weight

1.705 Kg/3.9lb

1.705 Kg/3.9lb
